Vulcan Online Condenser Tube Cleaning System

The Regular Problem: The fouling in shell & tube heat exchanger is unavoidable. The thickness of fouling inside your tube go on increasing (till you decide to clean it) reducing the heat transfer performance and increasing the system pressure. The direct impact of fouling is LOSS in profitability of any business. On one hand, it make your production costly by spending more on energy bills & on other hand you, lose revenue on account of production loss. The old way to clean your heat exchangers (HVAC, Process or Power plants) require costly shutdown, harmful chemicals and ongoing operating expenses with risk of damaging tubes.

The Permanent Solution: The new way begins with one little ball. This one little ball and dozen like it keeps heat exchanger tubes forever clean. We call it, Vulcan Online Condenser Tube Cleaning System (VOCCSYS). A proven technology tried, tested, approved and recommended by thousand of worldwide clients across HVAC, Chemicals, refinery process & power plant industries.

This is how the VOCCYS works. The ball start out of a ball collector, connected to your heat exchanger or condenser through the main inlet line. The window on the ball collector allows you to physically monitor the condition of balls. The VOCCYS include PLC controlled pump which forces water through pipe & into the ball collector. The system periodically injects the balls into the inlet pipe at the same time. Then the system water flow carries the ball into the inlet main pipe. The balls go to heat exchanger (condenser), where they are randomly distributed across the condenser tube. The balls flow through the heat exchanger (condenser) tube with normal system flow velocity. As the water pushes the ball through the tube, they clean residue of soft fouling before they built up in the tube to lower down the heat transfer efficiency or increase system pressure. As the ball exit the heat exchanger (condenser), they are collected in ball trap that has no moving parts and zero possibility of ball escape. Once the balls are in trap, the controller opens the valve, allowing balls to carry back in ball collector. This cycle repeats at a predetermined interval.

It’s amazing what VOCCYS can do to your business

  • It saves energy bill. (Up to 25% in HVAC system)

  • Eliminates costly downtime. (This saving is industry specific)

  • Extend the life of your capital equipment. (More than 20%.)

  • Lower down the maintenance cost.

  • Optimize the process efficiency.

  • Improve the power output up to 5% in case of power plant

The system often pays for itself in less than 1 year. In some cases its cost is recovered in few hours by saving production loss on account of avoiding compulsory shutdown. Please send us duly filled design request form to help us to promote this ECO-FRIENDLY TECHNOLOGY across Indian Industries which benefits us ALL.
